Drive Shaft Torque at Maximum Pressure
1699.3lb/ft
Drive Method
Gerotor Motor – Direct Drive
Mounting Bracket Design
Skid Steer Loader Coupler
Required Hydraulics
Standard Flow
Optimal Hydraulic Flow
42-83 L/min (11-22 gpm)
Optimal Hydraulic Pressure
145-235 bar (2100-3400 psi)
Overall Width – With Bracket
45in
Overall Length – With Bracket
23.5in
Overall Height
40.2in
Housing Diameter
9.9in
Swing Range
102 degrees
Swing Range (fore/aft)
120 degrees
Swing Range (L/R)
102 degrees
Weight
423.3lb
Motor Displacement
38in³
Bit Speed at Maximum Flow
127 rpm
Hex Output Shaft Size
2in
